18650 Cellakapacitás-mérő Modul Kijelzővel AE8 (5652)

18650 Cellakapacitás-mérő Modul Kijelzővel AE8 (5652) (Kategória: Tölthető Elemek)<p>18650 Cellakapacitás-mérő Modul Kijelzővel AE8</p>
<p> </p>
<p>Feature:</p>
<p>1. The blue segment on the upper end is the external discharge
terminal, and the lower end has the working indicator light of the
corresponding channel.</p>
<p>2. Voltage and current curve display, real-time voltage and
current, DC two-wire method to measure internal resistance</p>
<p>3. The U-shaped groove on the back is combined with the PCB
board, and the fan actively dissipates heat to form a heat
dissipation channel.</p>
<p>4. The 18650 battery holder uses a compact battery holder,
suitable for flat-head battery measurement.</p>
<p>5. Channel type: 8 independent channels, each is independent,
operates independently, and does not affect each other.</p>
<p>6. Channel synchronization: Supports 8-channel setting
synchronization, and you can also set the parameters of each
channel individually.</p>
<p>7. Cycle charging and discharging: In automatic mode, only one
charge-discharge-charge cycle is supported, and multiple cycles are
not supported.</p>
<p> </p>
<p>Product parameters:</p>
<p>Working voltage: DC5V 10A (standard bare metal, no power supply
included), overvoltage will cause the machine to burn</p>
<p>Power supply interface: : DC5.5 high current interface, : 5V
positive and negative solder joints</p>
<p>Power supply reverse connection protection: There is reverse
connection protection, reverse connection of power supply is
prohibited</p>
<p>Automatic mode: Program starts~Charging at 4.2V charging stop
voltage, charging current is less than the stop current for 30
seconds, first charging is completed~Stand (not charging or
discharging)~Discharge according to the stop voltage setting, the
load voltage is lower than the stop voltage 10 seconds, the
discharge is completed ~ let it stand (without charging or
discharging) ~ charge with the recharge voltage as the stop
voltage. When the recharge voltage is set to 4.2V, the charging
current is less than the stop current for 30 seconds, and the
program ends (the recharge voltage is not equal to When 4.2V, the
battery voltage reaches the recharging voltage, the program ends),
recharging is completed, the program ends, and the automatic mode
operation is completed.</p>
<p>Charging mode: Program starts ~ when the charging voltage is
set to 4.2V, the charging current is less than the stop current for
30 seconds, the program ends (when the charging voltage is not
equal to 4.2V, the battery voltage reaches the charging voltage,
the program ends) ~ charging is completed.</p>
<p>Discharge mode: The program starts ~ the load voltage is lower
than the stop voltage for 10 seconds, the program ends ~ the
discharge is completed</p>
<p>Activation mode: For use by professionals only, testers are not
allowed to leave the site during use! Forced charging at the
charging stop voltage will not stop automatically and needs to be
ended manually.</p>
<p>Charging current: Each channel is independent, up to about 1A,
and the charging current is not adjustable.</p>
<p>Charging stop voltage: 3.7V, 3.8V, 3.9V, 4.0V, 4.1V, 4.2V, a
total of 6 levels adjustable</p>
<p>Recharge stop voltage: 3.0V, 3.1V, 3.2V, 3.3V, 3.4V, 3.5V, 3.6V,
3.7V, 3.8V, 3.9V, 4.0V, 4.1V, 4.2V, a total of 13 adjustable
levels</p>
<p>End current: 100mA, 200mA, 300mA adjustable</p>
<p>Discharge current: Each channel independently discharges
non-constant current up to about 1A, and the discharge current is
not adjustable.</p>
<p>Discharge stop voltage: 2.0V, 2.1V, 2.2V, 2.3V, 2.4V, 2.5V,
2.6V, 2.7V, 2.8V, 2.9V, 3.0V, 3.1V, 3.2V, 3.3V, 3.4V, 3.5 V, 3.6V,
a total of 17 levels are adjustable.</p>
<p>Resting time: adjustable from 1 to 5 minutes.</p>
<p>Status preview: supports 8-channel status 1-screen preview</p>
<p>Single channel details display: supported</p>
<p>Single channel charge and discharge curve display: supported</p>
<p>Internal resistance detection: DC two-wire method to measure
internal resistance, only used for sorting analo
